| Properties: |
Modular chassis and hinged mounting base design provide easy access to field setup switches and wiring. |
| Dimensions: |
8.9 cm x 17.8 cm (3.5 in. x 7 in.) |
| |
|
| Operating Temperature: |
-40°C to +49°C (-40°F to +120°F) For UL Certificated installations, 0°C to +49°C (+32°F to +120°F) |
| Sensitivity: |
Low/High gain settings |
| Complies with Environmental Class II (EN50130-5) |
|
| |
|
| Height Range: |
3 m to 7.6 m (8 ft to 25 ft) recommended |
| Location: |
Mounts directly to ceiling or to standard 10.2 cm (4 in.) octagonal electrical box. |
| Internal Pointability: |
Coverage is adjustable ±10° horizontally, +2° to -18° vertically. |
| |
|
| Alarm Relay: |
Silent-operating form C relay. Contacts rated 125 mA, 28 VDC, 3 W maximum for DC resistive loads. |
| Tamper: |
Normally-closed (with cover in place) tamper switch. A wall (base) tamper is included. Contacts rated at 28 VDC, 125 mA, 3 W maximum. |
