| Zones: |
A total of 50 detection zones |
| Speed: |
0.2 m/s ~ 5.0 m/s (0.5 ft/s ~ 15 ft/s) |
| Pulse Count Selectability: |
1, 2, 3, or 4 pulses |
| |
|
| Dimensions: |
12.7 cm x 3.8 cm (5 in. x 1.5 in.) |
| Weight: |
176 g (6.2 oz) |
| |
|
| Humidity: |
0 to 95% humidity non-condensing |
| Operating Temperature: |
-10°C to +49°C (+14°F to +120°F) For UL Listed Applications, 0°C to +49°C (+32°F to +120°F) |
| |
|
| Height Range: |
2.4 m to 3.7 m (8 ft to 12 ft) recommended |
| |
|
| Relay: |
Dry Contact (NC) rated at 30 VDC, 500 mA, 10 W maximum |
| Tamper Switch: |
Integral NC, cover-activated |
